Measuring range (Floating decimal point):
+ Revolution (non-contact): 6 – 99999 rpm
+ Revolution (contact): 6 – 25000 rpm
+ Revolution(counter): 1 – 99999 rev
+ Speed: 1 – 3810 m/min; 36 – 99999 in/min; 3 – 12500 ft/min; 1.0 – 4167.0 yd/min
+ Length: 0.2 – 99999 m; 0.5 – 99999 ft; 0.01 – 99999 yd
Accuracy:
+ Revolution: 6 – 599 ±1 rpm ±1 digit; 600 – 25000 rpm ±2 ±1 digit; 25001 – 9999 ±0.01 % of reading ±1 digit
+ Speed and length: ±0.4% of reading ±1 digit
Measuring units:
+ Revolution: rpm
+ Total rotations (counter): rev
+ Speed: m/min; ft/min; yd/min; in/min
+ Length: m; ft; yd
Memory: 14 readings (10 readings, MAX, MIN, mean and last) are stored for 5 minutes after last use
Laser, class 2: Output<1 mW, wave length 760 nm, max. measuring distance 2 m
Resolution: Length: 0.02362 m/Impulse, revolution: 1 Impulse/revolution
Display: 5 digit LCD 12 mm high
Display update: 1 s
Over range indicator: ”OVR” flashes at the display
Auto power off: After 5 min of non-use
Power supply: Battery 3 x 1.5 V Type AA, (approx. 50 h continuous use)
Low battery indicator: ”LO BAT” flashes at the display
Temperature range: 5 – 45 °C
Air humidity: 85 % RH, max.
Housing: Polyamide, fiber-reinforced
Dimensions:149 x 64 x 31 mm (LxWxH)
Weight, net (gross): Approx. 180 g (400 g)
