Nominal Frequency Range: 1 GHz … 18 GHz
Usable Frequency Range: 800 MHz … 18 GHz
Isotropic Gain: 5 … 17 dBi
Antenna Factor: 25 … 44 dB/m
Nominal Impedance: 50 Ω
Standing Wave Ratio SWR typical: ≈ 1.5
Front to Back Ratio: > 25 dB (f > 1.3 GHz)
Cross Polarisation: > 25 dB (1 GHz … 18 GHz)
3 dB Beamwidth typ. (E-Plane): 90° – 8°
3 dB Beamwidth typ. (H-Plane): 60° – 7°
Connector: N-Connector female
Mount: 22 mm Tube, Indexing Ring
Width × Length × Thickness: 250 × 195 (408) × 142 mm
Weight: 1.4 kg
