Nominal Frequency Range: 0.7…10 GHz
Isotropic Gain: 5…13 dBi (f > 1 GHz)
Antenna Factor: 25…39 dB/m (f > 1 GHz)
Nominal Impedance: 50 Ω
Standing Wave Ratio SWR typical: 2
Standing Wave Ratio SWR max.: < 3 (f > 1.25 GHz)
Port Isolation: typ. > 30 dB
Cross Polarisation: typ. > 25 dB
3 dB Beamwidth (E-Plane): 40–80°
3 dB Beamwidth (H-Plane): 40–140°
Max. Input Power: 100 W (intermittent), 50 W (continuous)
Connector: SMA female
Mounting: Flange plate with 4 holes Ø 6.2 mm in square, drilling spacing 75 mm
Width x Length x Height:: 235 × 200 × 235 mm
Weight: 0.84 kg
