Frequency Range (nominal): 2-4 GHz
Frequency Range (useable): 1.9-4.6 GHz
Gain: ≈ 17-20 dBi
Antenna Factor: 19...23 dB/m
VSWR: typ. < 1.5
Front to Back Ratio: typ. > 27 dB
Half Power Beamwidth (E-Plane): 17° @ 2 GHz/ 13° @ 3 GHz/ 11° @ 4 GHz
Half Power Beamwidth (H-Plane): 19° @ 2 GHz/ 14° @ 3 GHz/ 16° @ 4 GHz
Connector: 7/16
Max. Input Power: 2 kW (2 GHz)/ 1 kW (4 GHz)
Max. Peak Input Power: 10 kW
Mounting Threads: 3/8" , M12
Dimensions:325 x 445 x 965 mm
Weight: 5.6 kg
Material: Aluminium
