Number of turns (per Coil): 8
Maximum coil current: 55 A, 5 min.
Nominal coil current: 34 A continuous
Coil spacing: 300 mm
Maximum magnetic field strength: 1060 A/m, 5 min.
Nominal magnetic field strength: 650 A/m continuous
Magnetic field strength @ 1 A Coil Current: 19.23 A/m
Conversion Current-Fieldstrength (Coil factor): 145.68 dBµA/m
Current required for 1 A/m: 52 mA
Conversion Current-Fieldstrength: 25.7 dB/m
Coil diameter: 588 mm
Mechanical dimensions: 0.64 m × 0.79 m × 0.42 m
Max. cubical shaped DuT: 32.5 × 32.5 × 32.5 cm
Terminals: 4 mm banana jacks / Screw terminals
Usable frequency range: DC – 800 kHz
Inductance (per coil): 91 µH
Inductance (pair of coils): 200 µH
Resistance (per coil): 28 mΩ
Coil capacitance (pair of coils): 49 pF
Resonance frequency (Pair of coils): > 1500 kHz
Weight: 17 kg
