Nominal frequency range: DC…1 kHz
Nominal measuring range: 0 … 7000 A/m (peak)
Extended measuring range: 0 … 9000 A/m (peak)
Nominal conversion factor: 1 (A/m) / mV
Load impedance: > 2 kΩ
Non-linearity error: 0.8 %
Power supply: 12 V DC ±3 % / 250 mA
Operating temperature ambient: 15°C – 30°C
Housing: Aluminium
Dimensions: approx. 470 × 42 × 28 mm
Mounting: D = 22 mm, L = 120 mm
Weight: 300 g
Connector: BNC female
