Nominal Frequency range:1 - 6 GHz
Useable Frequency range: 0.5 - 6.5 GHz
Connector: female 50 Ω N
Mounting tube: LH=560mm, d=22 mm
Index Ring:LR=190mm
Element length total:LE = 50 mm
Element diameter:D = 28 mm
Isotropic gain: typ. typ. -10....+2 dBi (1 - 6 GHz)
Antenna Factor: 32 ... 48 dB/m
SWR typ.: 1.5-5 (1.3 - 6 GHz)
Balun (low loss):1:1
Inversion Symmetry: typ. < 0.5 dB (1 - 6 GHz)
Cross Polarisation Rejection: < -20 dB
Max. Input Power: 20W
Half-Power Beamwidth (E-plane): 84° - 45°
Weight: 400g
