Nominal frequency range: 230 MHz ... 2.3 GHz
Usable frequency range: 200 MHz ... 4 GHz
Isotropic gain: 7 dBi ± 1 dB
Antenna factor: 12 ... 32 dB/m
Nominal impedance: 50 Ω
Standing wave ratio (SWR) max.: < 2.5
Standing wave ratio (SWR) typical: < 1.5
Front to back ratio: 20 dB
Cross polarisation: >10 dB (230 MHz ... 1 GHz)
3 dB beamwidth typ. (E-Plane): 45° – 65°
3 dB beamwidth typ. (H-Plane): 90° – 120°
Max. input power: 1000 W (≤230 MHz) / 300 W (1 GHz)
Connector type: N-connector female
Mount: 22 mm tube, indexing ring
Dimensions (W × L × T): 650 × 790 × 82 mm
Weight: 1.6 kg
Storing case (optional) (W × L × H): 725 × 610 × 145 mm
