INPUT
- Voltage: 100-120VAC/ 200-240VAC ±10% Auto Range
- Frequency: 50/60 Hz ± 5%
- Fuse: 3.15A/ 250VAC Fast-Blow
DIELECTRIC WITHSTAND TEST MODE
- Output rating: DC 0-6.00 kVDC, 5.00 mA
- Voltage setting: 0-6.00 kVDC
+ Resolution: 0.01 kV
+ Accuracy: ± (1.5% of setting + 5V)
- DC Output Ripple: <5% (6 kVDC/5mA at Resistive Load)
- Dwell timer: 0, 0.2-60 sec, (0=continuous), 0.1 sec/step
- Ramp timer: 0.2-180 sec, 0.1 sec/step
- Leakage failure settings
+ DC Hi-Limit: 0.02-5.0mA
+ Lo-Limit: 0-5.00mA
+ Resolution: 0.01mA
+ Accuracy: ±(2% of reading + 0.02mA)
GENERAL SPECIFICATIONS
- Continuity feature
+ Range: 0.0-1.50Ω
+ Resolution: 0.01Ω
+ Accuracy: ±(2% of setting + 0.02Ω)
- Memories: 5 (10 optional)
- Remote I/O:
+ Input: Test, Reset, Interlock
+ Output: Pass, Fail, Test-in-Process
- 3mA DC current limit (optional)
+ Range: 0.00-3.00mA
+ Resolution: 0.01mA
+ Accuracy: ±(2% of setting +0.02mA)
- Safety mark: CE/cTUVus
- Dimensions (WxHxD): 8.5" x 3.5" x 11.9" (215 x 88.1 x 300mm)
- Weight: 12lbs (5.46Kg)
