Condenser Type: Vertical-type
Evaporating Flask: 0.1-5Lit, Included 1Lit Evaporating Flask
Receiving Flask: 0.1-3Lit, Included 1Lit Receiving Flask
Controller & Display: PID Controller, Digital Display
Rotation Speed: 10-300rpm
Evaporating Capability: Max 23ml/min
Cooling Surface: 1,600cm²
Heating Bath Capacity & Temp. Range
-Standard (Included): 2.5Lit Oil Bath, Up to 200°C, for 0.1-2Lit Evaporating Flasks
External(215×205Xh179mm), Internal(197×187Xh117mm)
-Optional: 5.5Lit Oil Bath, Up to 200°C, for Max 5Lit Evaporating Flasks
External(324x269Xh209mm), Internal(305X250Xh118mm)
Lifting Type: Adjustable Automatic Electric Lifting: up to 195mm
Programmable Prefer Height and Digital Display Height
Immersion Angle: Adjustable 10-steps Angle 1° - 50°
Vacuum Seal: Double Sealing Rings made of Teflon + Viton Material
Power Consumption: Rotation Motor(100W), Heating Bath: Included 2.5Lit Bath(1,200W/220V, 1,100W/110V), Optional 5.5Lit Bath(1,500W/220V, 1,100W/110V)
Material
-Housing: Aluminum Die Casting
-Heating Bath: External(PBT), Internal(Ceramic-coated SUS304)
Dimension & Net Weight: 510×438xh519(Max. 714)mm, 16kg
Electrical Reqts: AC220V, 50/60Hz
