Performance
Measurement Range: 0 to ±19.99 kV / inch
Measurement Accuracy: Better than ±5% of reading, ±2 counts
Measurement Stability: ±10 counts
Front Panel Meter
Voltage Display: 3-1/2 digit LED display
Sampling Rate: 3 readings per second
Features
Ranging System: LED distance indicator; aligned targets indicate 1"
Range: LED distance indicator
Rotary Zero Knob: Sets the zero-reference point
Low Battery Indicator: An LCD icon indicates when the battery is low
Hold Switch: Retains the LCD display reading when depressed
General
Dimensions: 0.9" H x 2.8" W x 4.9"L
(24 mm x 70 mm x 126 mm)
Weight: 4.9 oz. (140 g) with battery:
Operating Conditions
Temperature: 50 to 86ºF (10 to 30ºC)
Relative Humidity: To 80%, non-condensing
Altitude: To 2000 m
Certifications: CE
Power Requirements
Power: One (1) 9-volt alkaline battery
Operating Time: Greater than 50 hours, with a new battery at 21ºC continuous
