Processor: ARM Cortex-M3 @ 72MHz
Input channel: 8 electrically insulated digital inputs
Operating temperature range: -20 to +55 °C | -4 to 131°F
Dimensions housing: 71.6x89.7x54.9 mm | 2.80”x3.50”x2.13”
Mounting: 35 mm DIN-rail
Weight: 125g | 4.4oz
Power supply: 24VDC +/- 10% (uses main power supply through internal DIN-rail connection, no external wiring is needed)
Power consumption: ≈50mA
Power reference: Isolated 12VDC internally provided (no external wiring is needed)
Minimum input voltage: 0VDC
Maximum Input voltage :12VDC
Input resistance: > 200k
Resolution: 8bits
Acquisition time: 160 ms
