Direct access to our certified experts
Operable with: Provided sensors (voltage output)
Main dynamic inputs: 8 channels (for vibration and ultrasound)
Auxiliary inputs: 4 channels (ex: tachometer, temperature, etc.)
USB port: 1 Host, used as power supply only
Status indicators: 13xRGB LED
Power supply: V 20-26 V DC, 24 V DC nominal
Power consumption: W <12
Internal battery (for safe shutdown only): Lithium-Po, 3.7 V 1300 mAh
Configuration system: Integrated local webserver application
CPU: ARM Cortex™-A9 Quad Core (NVIDIA® Tegra™ 3)
RAM: GB 1
Size of the unit: mm(inch) Lxlxh: 162x95x27 (~6.38x3.74x1.06)
Weight of the unit: kg (oz) 0.55 (~19.4)
Operating temperature range: °C (°F) -30 to +44.5°C (-22 to 111.2 °F), non-condensing
Humidity: % 95% RH
