Power Supply: AC380V±10%, 50/60Hz
Power: 7.75KW (Max), Top heater (1.45KW), Bottom heater (1.2KW), IR Preheater (4.8KW), Other (0.3KW)
PCB Size: 632*520mm (Max); 6*6mm (Min)
BGA Chip Size: 80*80mm (Max); 3*3mm (Min)
IR Heater Size: 570*435mm
Temperature Sensor: 5 Pcs
Operation Method: 10" HD touch panel (1080P 16:9)
Control System: Panasonic PLC + Temperature control module
Display System: 15" HD industrial display (1080P 16:9)
Alignment System: 2 Million Pixel HD digital imaging system, automatic optical zoom with laser red-dot indicator
Vacuum Adsorption: Automatic
Alignment Accuracy: ±0.01mm
Temperature Control: K-type thermocouple closed-loop control with accuracy up to ±1℃
Feeding Device: Yes
Positioning: V-groove with universal fixture
Dimensions: L1000*W835*H960mm
Weight: 130.5KG
