Power supply: 50/60HZ 220V single phase
Processing length: 13mm (Full Length)–99999mm
Wire processing range: Precision AWG#20–AWG32# (2 rounds of wire feeding); Large wire type AWG#18–AWG14# (4 rounds of wire feeding)
Terminal Machinable Range: Spacing 0.8–3.96mm, can be customized partial closed continuous insertion terminal and single terminal
Capacity: 3200–3800PCS/H (13–200mm long) The actual efficiency is subject to the actual measurement of the wire
Stripping length: A end 0–6mm; B end 0–10mm
Cutting accuracy: ±(0.2%*L+1)mm
Air pressure: 0.5–0.7Mpa (5–7KG/m³)
Dimensions: 1400×800×1500mm
Matching pay-off frame size: 920×560×1300mm
Weight: About 450KG±15KG; The weight of the matching pay-off frame is about 80KG
