Display : 7 inch touch screen
Processing range : 6 - 120mm²
Wire diameter : Φ30mm
Stripping length: Front full stripping: 1-300mm; Front half stripping: 1-1000mm/ End full stripping: 1-150mm; End half stripping: 1-500mm
Dimensions(L*W*H) : 1400*720*1460mm
Net weight : 300kg
Cutting length : 1mm-999999.99mm
Cutting tolerance : ≤0.002*L(L=cutting length)
Blade material : High-quality high-speed steel
Rotary cutter material: White steel/tungsten steel (optional)
Productivity : 1500PCS/hour 2000PCS/hour 500-1000PCS/hour (depending on the length and size of the cable)
Drive mode : 16 rollers drive 32 rollers drive 32 rollers drive (feeding-stepper motor, blades-servo motor, rotary cutter-servo motor)
Wire feeding method : Belt feeding, no embossing or scratches on the cable
Lift operation mode : Digitally adjust the height of the pressure roller
Power supply : AC220V 50/60Hz; 110V 50/60Hz
Air source: 0.5Mpa-0.8Mpa
