Optical
Wavelength: 635nm/523nm
Optical Output Power: 1mW up to 50mW
Stability: <1%
Laser Operation: Continuous
Laser Structure: Single Mode Laser
Fan Angle Line Generator: 4º, 15º, 35º, 45º, 60º, 75º, 90º
Minimum Line Thickness: <1mm up to 1 meter
Fan Angle Cross Line: 25º full fan angle
Minimum Line Thickness: <1mm up to 1 meter
Spot Size: Adjustable or Collimated
Minimum Spot Size: <60μm at <10” distance
Environmental
Protection: Dustproof & Sh℃k Proof
Electrical
Operating Voltage: 3 to 5 VDC
Operating Current: <60 mA
Control Circuit: Auto Power Control
AC wall transformer adaptor: DC 4.5 V 700mA
Mechanical
Dimension: 4” long x 0.785” diameter
Housing: Hard black anodized finish
Operating Temperature: -10ºC to +50ºC
Storage Temperature: -40ºC to +80ºC
