Specifications
Output signal options:
5V(with 5Vdc power) or 24V(with 24Vdc power) TTL impulse
4-20mA current with 24Vdc power
Indicator: LED, flash when there is an impulse
Operating Temperature Range: -20~70 Celsius degree
RPM range: 60 ~ 60000 r/minute
Laser distance to the shaft: 20~2000 mm,depending on reflecting condition.
Connector type: Sendig 301(plug supplied together)
Power source: 4.5~5.5Vdc, or 20~28Vdc, 28mA
Dimension (mm): 65(Length) × 25(width) × 25(High)
Weight: 50g
