Switch: without
Nominal width: DN 32
Process connection: female thread G 1 1/4
Switching range: 20 - 100 l/min
Pressure loss: 5 bar at Qmax
Qmax.: to 120 l/min
Tolerance: ±10 % of full scale value
Pressure resistance: PS 200 bar
Media temperature: -20..+120 ℃
Ambient temperature: -20..+70 °C
Media: oil
Materials medium-contact
Brass construction: CW614N nickelled, CW614N, 1.4305, 1.4310, hard ferrite
Non-medium contact materials: CW614N nickelled, PC, acrylic
Installation location
Standard: horizontal inwards flow from the left; other installation positions are possible; the installation position affects the switching point and range.
For details please see Datasheet
