No alarm output A3,A4
Power supply
Supply voltage : 24 V DC, ± 15 %
: < 5 VA
Operating temperature : -10..+55 °C
CE-conformity : EN 61326-1:2013; EN 60664-1:2007
Input
Fault function : break of wire (RTD Pt100/1000, Thermocouple) and short-circuit (only Pt100/1000)
RTD : Pt100 (3-wire) -100.0..+600.0 °C
Pt1000 (3-wire) -100.0..+300.0 °C
: Thermocouple (TC)
type J -100.0..+800.0 °C
type K -150..+1200 °C
type N -150..+1200 °C
type S -50..+1600 °C
cold junction compensation integrated
Accuracy : <0.1 %, ±1 Digit
Display : Graphic LCD-Display, 128 x 64 Pixel, with white back-lite
Output
Alarm A1-A4 : relay SPDT
< 250 V AC < 250 VA < 2 A
cos Phi ≥ 0.3
< 300 V DC < 40 W <2 A
- Accuracy : 0.2 %;TK 0.01 %/K
Fault indication : for broken line or short circuit detection
→ analog output (programmable)
0 mA, < 3.6 mA or >21.5 mA
→ Alarm relays
min. or max. function programmable
Case : Polyamide (PA) 6.6 , UL94V-0
TS35 acc. to DIN EN 60715:2001-09
Weight : approx. 450 g
Connection : screw terminals 0.14..2.5 mm²
AWG 26..AWG14
Protection class : case IP30, terminals IP20 acc. to BGV A3
