Flow Ranges:
Standard: 600 to 5.000 cc/min
(Volumetric and STP flow averaging available)
Accuracy: ±1% of reading or 2 cc/min, whichever is greater at standard conditions (21.1°C and 101.3 kPa)
Environmental Sensors: Ambient Temperature and Pressure present in flow stream
Averaging Function: User selectable sample sampling time in seconds. Four pre-sets and user defined (5 – 5.000 sec.)
Gas Compatibility: Non-corrosive, Non-condensing
Flow Direction: Pressure and Suction
AC Charger: 5 VDC
Charging Cable: USB-C to USB-A Cable
Battery: Rechargeable lithium nickel cobalt aluminum oxide (NCA) battery
Battery Charge Time: Less than 6 hours
Operation Time: Up to 24 hours* Up to 400 calibrations on a single charge**
Operating Temperature: 0 to 45°C (32 to 113°F)
Storage Temperature: -20 to 60°C (-4 to 140°F)
Operating Humidity: 0 – 85% RH, non-condensing
Operating Pressure: 700 mbar to 1546 mbar (525 mmHg to 1160 mmHg)
Operating Altitude: -1.000 m (-3280 ft) to approximately 3050 m (10.000 ft) above sea level
Display: Multi-color LCD capacitive touchscreen
Connectivity: USB-C to PC for Gilian Connect. Bluetooth™ option for Gilian Mobile (optional at time of purchase by customer)
SmartCal: SmartCal capable with GilAir Plus Communications Dock. Accessory Cables Required (not included)
Report Generation: Flow verification events are recorded and saved as viewable reports on the unit and are available for download through provided software
External Dimensions: (HxWxD) 5.0 in x 3.6 in x 2.0 in
Tube Adapters:
0.375 in OD straight barbed (STD & HIGH)
Weight: 0.75 lbs (0.4 kg)
IP Rating: IP54
With Carry Case
* Running continuously with screen dimming function.
** Based on 30 second averaging and pump adjustments up to 2 minutes each, full brightness.
