Measurement Range (pH): 0.00 to 14.00pH, 0.01 pH resolution, +/- 0.01 accuracy
Measurement Range (ORP/mV): -1999mV to 1999mV, 1mV resolution, +/- 2mV accuracy
Temperature Range: -20 °C to 110 °C , 0.1 °C resolution, 0.2 °C accuracy
Current Output Range: 2.00mA to 24mA, 0.01mA resolution, +/-0.005mA accuracy, 500V input/output isolation
Enclosure: NEMA 4X IP65, ABS case with push-button control pad; HWD: 3.9” (99.1 mm) x 3.9” (99.1 mm) x 2.9” (74.7mm)
Mounting Options: Panel, wall, DIN rail, or pipe mounting
Ambient Operating Temperature: 0° C to 60° C
Storage Temperature: 10° C to 70° C
Ambient Humidity: 0 to 95%, non-condensing
Location: Designed for non-hazardous environments
Maximum Sensor to Transmitter Distance: 30 feet (9.1 meters)
Conduit Openings: 2 each 3/8″ NPT openings (cord grips included)
Temperature Input: 2-wire Pt1000 RTD with automatic compensation
Power Requirement: 12-24 VDC, max 600Ohm load
Warranty: One year limited warranty
Weight: Approx. 1lb (0.45kg)
