Measuring ranges: 0~40Ω / 0~400Ω / 0~4kΩ / ±(2%rdg+2dgt)
resolution
0-20Ω : 0.01Ω
0-200Ω : 0.1Ω
0-2000Ω : 1Ω
Measuring Earth voltage: 0-200 Vac / ±(1%rdg+2dgt)
Dimensions: 250(L) × 190(W) × 110(D)mm
Weight: 1500g
Power source: 1.5V (AA) × 8
|
||||||||||||||||||||||||||||||||||
| FEATURES | ||||||||||||||||||||||||||||||||||
| ● Capable of measuring earth resistance and earth voltage. ● 2mA measuring current permits the testing of earth resistance without tripping earth leakage current breakers in the circuit under test. ● The leads are supplied as standard accessories for simplified two-wire measuring system. ● Battery operated. ● Data hold function. ● Battery test indication. ● Calibration performed with supplied test leads. |
||||||||||||||||||||||||||||||||||
| SPECIFICATIONS | ||||||||||||||||||||||||||||||||||
|
