Accuracy: ± 0.5% f.s
Weight :Approx. 1.7kg
Dimension :196(L) × 170(W) × 87(D)mm
NOTE: chose the product by the range:
1. AC Ammeter
a. 2 range:
20/100 mA No.: 1301
50/100 mA No.: 1302
100/500 mA No.: 1303
0.2/1 A No.: 1304
0.5/1 A No.: 1305
1/5 A No.: 1306
2/10 A No.: 1307
5/25 A No.: 1308
10/50 A No.: 1309
5/50 A No.: 1322
b. 3 range:
20/100/500 mA No.: 1310
100/500/1000 mA No.: 1311
0.2/0.5/1 A No.: 1312
0.5/1/2 A No.: 1313
2/5/10 A No.: 1314
5/10/20 A No.: 1315
c. 4 range:
20/50/100/200 mA No.: 1316
0.1/0.2/0.5/1 A No.: 1317
0.5/1/2/5 A No.: 1318
2/5/10/20 A No.: 1319
10/30/100/300 mA No.: 1321
2. DC Ammeter
a. 2 range:
50/100 µA No.: 1403
100/500 µA No.: 1404
500/1000 µA No.: 1405
10/50 mA No.: 1406
50/100 mA No.: 1407
50/500 mA No.: 1408
b. 3 range:
10/30/100 mA No.: 1409
0.1/0.3/1 A No.: 1410
1/3/10 A No.: 1411
3/10/30 A No.: 1412
c. 4 range:
10/30/100/300 µA No.: 1413
0.1/0.3/1/3 mA No.: 1414
1/3/10/30 mA No.: 1415
10/30/100/300 mA No.: 1416
0.1/0.3/1/3 A No.: 1417
1/3/10/30 A No.: 1418
