Stabilized Laser Source:
Wavelength (±20nm): 1310/1490/1550nm
Power Range (dBm): -70 ~ +10 (-60 ~ +10@850nm)
Accuracy: ± 5% ± 0.01nW (±0.5 dB@850nm)
ORL Function: -
Spectrum Width: ≤5nm
Emitter Type: FP-LD
Output Power: >-4dBm
Power Stability: ±0.05dB/15min; ±0.10dB/8hr
Output Mode: CW, 270Hz, 1KHz, 2KHz
Optical Power Meter:
Calibrated Wavelength: 850, 1300, 1310, 1490, 1550, 1625nm
Display Unit: W/mW/μW/nW/pW/dBm/dB(REF)
Detector Type: InGaAs
Resolution: 0.01dB
Auto Wavelength Identification : Yes (With ShinewayTech specified Stabilized Laser Source)
MOD Identification: 270Hz, 1KHz, 2KHz
Optical Loss Test:
Link Loss Range: 50dB (1550nm, 200km)
Link Loss Accuracy: ±0.25dB
Link Loss Test Time: < 2 seconds per wavelength
General Specifications:
Connector: FC (Interchangeable SC, ST)
Data Storage: 1000 records
Data Interface: USB
Backlight Display: Yes
Auto Off: Yes (Auto-off after 5 minutes idle)
Power Supply: Lithium Battery/ AC Adapter
Battery Life: Continuous operation ≥35 hours
Operating Temperature: -20ºC ~ 50ºC
Storage Temperature: -40ºC ~ 70ºC
Relative Humidity: 0 ~ 95% (Non-condensing)
Weight: 350g
Dimensions (H × W × T): 177×80×44mm
* Specifications subject to change without notice.:
Ordering Information
Standard Package Includes:
Instrument, Lithium battery, AC adapter/charger, USB cable, software CD, soft carrying case, warranty card, CE certificate, certificate of calibration, user manual.
