TRAVEL
X axis (mm): 650
Y axis (mm): 430
Z axis (mm): 340
Spindle nose to table surface (mm): 150 ~ 490
WORK TABLE
Table size (mm): 750 x 400
T- slot (W x No. x P) (mm): 14 x 3 x 125
Max. loading (average) (kg): 250
SPINDLE
Max. spindle speed (rpm): 10000 (Fanuc), 12000 (Mitsubishi)
Drive type: Direct drive
Motor power output (kW): 3.7 / 5.5
Spindle taper: BT - 30
FEEDRATE
Rapid traverse speed on X/Y/Z axes (M/min): 48 / 48 / 48 (Mitsubishi); 36 / 36 / 36 (Fanuc)
Max. cutting feedrate (M/min): 12
Servo motor of X/Y/Z (kW): 1.5 / 1.5 / 2.0 (Mitsubishi); 1.2 / 1.2 / 1.8 (Fanuc)
AUTOMATIC TOOL CHANGER ():
Tool capacity (pcs): 16T (21 T)
ATC type: Clam type
Max. tool diameter (w/ adjacent tool) (mm): Ø100
Max. tool length (mm): 200
Max. tool weight (kg): 3
OTHER
Total require power (kva): 15
Machine dimension (L x W x H) (mm): 1900 x 2575 x 2410
Machine weight (kg): 3000
