Application: Outdoor
Light source: Infrared light (905 nm, ± 10 nm)
Laser class: 1 (IEC 60825-1:2014, EN 60825-1:2014)
Aperture angle: Horizontal 85° (Working range with 4 scan layers, 25° extension of working range with 2 scan layers to a total of 110°) / Vertical 3.2°
Scanning frequency: 12.5 Hz ... 50 Hz, object tracking at 12.5 Hz
Angular resolution: 0.125° / 0.25° / 0.5°
Working range: 0.5 m ... 320 m
Scanning range: At 10% remission 50 m / At 90% remission 150 m
Connection type: Circular plug-in connector
Supply voltage: 9 V ... 27 V
Power consumption: 8 W
Housing color: Gray (RAL 7042), black (RAL 9005)
Protection class: III (EN 50178 (1997;10))
Enclosure rating: IP69K
Weight: 0.77 kg
Dimensions (L x W x H): 91.3 mm x 164.5 mm x 88 mm
Interface: Ethernet ✔, TCP/IP
