Variant: Lite
Application: Indoor
Resolution power: High Resolution
Light source: Infrared (905 nm, ± 10 nm)
Laser class: 1 (EN/IEC 60825-1:2014 (Ed.3), EN/IEC 60825-1:2007 (Ed.2) CAN/CSA-E60825-1:2015-11 (Ed.3))
Aperture angle: Horizontal 190°
Scanning frequency: 25 Hz / 35 Hz / 50 Hz / 75 Hz
Angular resolution: 0.25° / 0.5° / 1°
Scan field flatness: Scan field flatness combined: ± 0.72° / Typical conical error: 1 sigma value - 0.11° ± 0.1° / Typical tilt: 1 sigma value + 0.15° ± 0.08°
Heating: Self-heating
Working range: 0.2 m ... 80 m
Scanning range: At 10% remission 26 m
Measurement accuracy: ± 12 mm
Spot size: Divergence: 4.7 mrad At the viewing window: 13.5 mm
Amount of evaluated echoes: 2
Connection type: 1 x M12 round connector / 1 x System plug with screw terminal block, incl. 2 x cable glands
Supply voltage: 24 V DC, ± 20 %
Power consumption: 22 W
Housing: AlSi12
Housing color: Light blue (RAL 5012)
Window material: Polycarbonate, scratch-resistant coating
Enclosure rating: IP65 (EN 60529, Section 14.2.7)
Weight: 3.7 kg
Dimensions (L x W x H): 160 mm x 155 mm x 185 mm
