Application: Outdoor
Light source: Infrared (886 nm)
Laser class: 1, complies with 21 CFR 1040.10 except for the conformance according to “Laser Notice No. 56” from May 8, 2019 (IEC 60825-1:2014, EN 60825-1:2014)
Aperture angle: Horizontal 360°
Scanning frequency: 12.5 Hz / 25 Hz
Angular resolution: 0.02° / 0.04° / 0.06° / 0.08° / 0.1° / 0.12° / 0.2° / 0.24°
Working range: 0.2 m ... 130 m
Scanning range: At 10% remission 40 m / At 90% remission 130 m
Connection type: 3 x M12
Supply voltage: 10 V DC ... 30 V DC
Power consumption: Typ. 13 W, Max. 20 W
Housing: AlSi12
Housing color: Gray (RAL 7042)
Enclosure rating: IP65 (IEC 60529:1989+AMD1:1999+AMD2:2013) / IP67 (IEC 60529:1989+AMD1:1999+AMD2:2013)
Protection class: III (EN 61140 (2002-03))
Electrical safety: IEC 61010-1:2010-06
Weight: 1.7 kg
Dimensions (L x W x H): 151.9 mm x 150 mm x 126.7 mm
