Measurement principle: HDDM+
Application: Outdoor
Light source: Infrared (850 nm)
Laser class: 1 (IEC 60825-1:2014, EN 60825-1:2014)
Aperture angle: Horizontal 275° / Vertical 7.5° (Over 4 scan layers)
Scanning frequency: 50 Hz, 4 x 12.5 Hz
Angular resolution: 0.25°
Heating: Self-heating
Working range: 0.2 m ... 64 m
Scanning range: At 10% remission 16 m / At 90% remission 30 m
Spot size: 10.4 mrad x 8.7 mrad
Amount of evaluated echoes: 3
Connection type: M12 round connectors with swivel connector
Supply voltage: 10 V DC ... 30 V DC
Power consumption: ≤ 13 W, Start-up phase max. 30 W for 1 s
Housing: AlSi12, optics cover: PC
Housing color: Gray (RAL 7042)
Enclosure rating: IP65 (IEC 60529:1989+AMD1:1999+AMD2:2013) / IP67 (IEC 60529:1989+AMD1:1999+AMD2:2013)
Protection class: III (IEC 61140:2016-11)
Electrical safety: IEC 61010-1:2010-06
Weight: 1.2 kg
Dimensions (L x W x H): 151.9 mm x 150 mm x 92.5 mm
Scan/frame rate: 55,000 measurement point/s ... 165,000 measurement point/s
Response time: 4 layers, typ. 20 ms / 1 layer, typ. 80 ms
Ethernet: ✔, TCP/IP, UDP/IP
Digital inputs/outputs: I/O (8 (Multiport))
