Measurement principle: HDDM+
Application: Indoor
Light source: Infrared (850 nm)
Laser class: 1 (IEC 60825-1:2014, EN 60825-1:2014)
Aperture angle: Horizontal 200°
Scanning frequency: 14.5 Hz
Angular resolution: 1°
Working range: 0.05 m ... 3 m
Scanning range: At 10% remission : 1.2 m ... 1.5 m, depending on the angle
Connection type: 1 x 5-pin M12 male device connector (rotatable)
Supply voltage: 9 V DC ... 28 V DC
Power consumption: Typ. 2.2 W
Output current: ≤ 100 mA
Housing color: Light blue (RAL 5012)
Weight: 90 g, without connecting cables
Dimensions (L x W x H): 60 mm x 60 mm x 75.8 mm
Enclosure rating: IP65 (IEC 60529:1989+AMD1:1999+AMD2:2013)
