Bandwidth: 200MHz
Sample rate (Max.): 1GSa/s
Waveform capture rate (Max.): 100.000wfm/s (normal mode), 400.000wfm/s (sequence mode)
Channels: 2+EXT
Memory depth (Max.): 7Mpts/CH (not interleave mode); 14Mpts/CH (interleave mode)
Trigger type: Edge, Slope, Pulse width, Window, Runt, Interval, Dropout, Pattern, Video
Serial trigger and decoder (Standard): I2C, SPI, UART, CAN, LIN
I/O: USB Host, USB Device, LAN, Pass/Fail, Trigger Out, Sbus(Siglent MSO)
Probe (standard): 4/2pcs passive probe PP215
Display: 7 inch TFT–LCD (800x480 pixels)
Weight: 2.5kg
Standard accessories
USB cable: 1
Quick Start: 1
Passive probe: 4/2
Certification: 1
Power cord: 1
Optional accessories
Isolated Front End: ISFE
STB Demo Source: STB-3
High voltage probe: HPB4010
Current probes: CP4020/CP4050/CP4070/CP4070A/CP5030/CP5030A/CP5150/CP5500
Differential probes: DPB4080/DPB5150/DPB5150A/DPB5700/DPB5700A
Rack Mount: SDS1X-E-RMK
