Workpiece
Max. Mass: 100 g
Max. Diameter: ø100mm
Journal diameter: ø1.0 to 4.0mm (Replaceable adapter)
Mechanical unit
Motor: AC servo motor, 100W
Chucking Adapter: Air Collet Chuck
Balancing speed: 1,500 to 3,000 min-1
Bearing support system: Soft type
Angle of unbalance index: Automatic indexing of spindle
Measuring unit
Balancing plane: 1or 2 plane
Eccentricity correction: Included
Min. Achievable Unbalance: 1.0µm
Graphic display: 5.7" TFT color LCD with touch screen
Min. unbalance indication: 0.001mg
Indication mode: Polar coordinates and (3 to 99) components of unbalance vector (add or remove of unbalance correction masses are selectable)
No. of stored work data: 50 data (No limitation when use with USB memory)
Judgment of measured result: Judgment with set limit value
Data transfer: Measured data can be transferred to PC or stored USB memory -optional
Others
Power supply: Single-phase AC100V
Dimensions: 318(W) x 624(L) x 522(H)mm
Mass: Approx. 47kg
