Core: ARM Cortex-M33
Antenna: Inverted-F PCB Trace
Data Rate: 1 Mb/s
Frequency: 2.4 GHz
Shielding: Shielded
Dimensions: 22.5 mm x 15.5 mm x 2.25 mm
Memory Size: 1 MB
Output Power: 12.5 dBm
Interface Type: I2C, UART
Mounting Style: PCB Mount
Moisture Sensitive: Yes
Modulation Technique: GFSK, O-QPSK DSSS
Receiver Sensitivity: - 97 dBm, - 104 dBm
Supply Voltage - Max: 3.8 V
Supply Voltage - Min: 1.8 V
Operating Supply Current: 63.8 uA
Operating Supply Voltage: 3 V
Supply Current Receiving: 9.4 mA
Supply Current Transmitting: 70 mA
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
Protocol - ANT, Thread, Zigbee - 802.15.4: Thread, Zigbee
