Gain: 2.15 dBi
VSWR: 2
Style: I-Bar
Width: 22 mm
Height: 5 mm
Length: 115 mm
Frequency: 850 MHz, 900 MHz, 1.8 GHz, 1.9 GHz, 2.1 GHz
Impedance: 50 Ohms
Cable Type: 1 M RG174
Application: Cellular Applications, ISM Applications
Unit Weight: 25 g
Cable Length: 1 m
Polarization: Vertical
Power Rating: 60 W
REACH - SVHC: Details
Mounting Style: Adhesive Mount
Frequency Range: 850 MHz to 2.1 GHz
Number of Bands: 4 Band
Center Frequency: 850 MHz, 900 MHz, 1.8 GHz, 1.9 GHz, 2.1 GHz
Mechanical Style: Module
Maximum Frequency: 2.1 GHz
Minimum Frequency: 850 MHz
Termination Style: Connector
Protocol - Sub GHz: ISM
Antenna Connector Type: SMA Male
Maximum Operating Temperature: + 75 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, GPRS, WCDMA
