Display Mode: CIELAB, CIELCH, CIEXYZ, CIELUV, HunterLAB, sRGB
Color Difference Formula: △E*ab, △ECMC, △EISO, △ECIE94, △EFCMⅡ, △ELuv, △Ehunter, △EsRGB
Yellowness and Whiteness: Ganci whiteness, ISO brightness, YI yellowness
Illumination Condition: CIE Recommendation: 8/d 45/0 Optional
Light Source: LED blue excitation
Sensor: Photodiode array
Measurement Caliber:φ4mm/φ8mm/φ16mm Alternative
Measurement Condition:
Observer: CIE 10° Standard observer
Light source: A C D50 D65 F2(CWF) F7 F11(TL84) F12(U30)
Contain light way: SCI SCE
Measurement Range: L: 0 to 100
Repeated Accuracy: △E<0.03(take the deviation average after 30 times measuring the whiteboard)
Table Difference: △E<0.2
Measurement Interval: 0.5 Sec.
Average Measuring Function: Average measuring frequency: 1-32 times
Color Simulation Function: yes
Storage Capacity:
Type sample data : 100 with testing sample data: 200
Whiteness/yellowness data: 200
Language Patterns: English/Simplified Chinese/Traditional Chinese
Quality Control Software: 《Color-Analysis System》 software
Battery Charging Time: 8 hrs
Battery: Li-ion battery, 5000 times Measurement
Lifetime of Bulb: 5 years more than 1.6 million measurements
Display Screen: TFT true color 2.8inch@(16:9) Resolution ratio:400×240
Interface of External: USB2.0 (USB-B)- data communication with 《color analysis system》software; RS-232 (115200bps)- connected with micro printer
Working Temperature Range: 0℃-40℃（32℉-104℉)
Storage Temperature Range: -20℃-50℃（-4℉-122℉)
Humidity Range: Relative humidity less than 85%,without condensation
Weight: 700g
Size: 199*68*90mm
Size of Exterior Package: 400*240*340mm
Standard Accessories: Standard whiteboard/Standard black cavity/3000mAH Li-ion battery/AC adapter/USB Data line/CD《Color analysis software》/User manual/Warranty card
Optional Accessories: Flour measuring device/Liquid measuring device/Micro printer
