Max swing over bed: 2080mm
Max swing over carriage: 1600mm
Max swing over gap: 2420mm
Weight of workpiece: 10tons
Center distance: 2m,3m,4m,5m,6m,8m,10m,12m
Gap length: 600m
Bed width: 1100mm
Main spindle hole: F130mm
Spindle taper: Metric 140#
Spindle speed: 3.15-315r/min or 2-200r/min or 2.5-250r/min./21 steps counter clockwide;12steps counter clockwide
Metric thread: 44kinds 1-120mm
Inch thread: 31kinds 1/4-24tpr
Mould thread: 45kinds 0.5-60mm
Diametric thread: 38kinds 1/2-56DP
Longitudinal feeding range: 56kinds 0.1-12mm
Cross feeding range: 56kind 0.1-12mm
Rapid feeding (Long/Cross): 1200mm/min,1800mm/min
Tool section: 45*45mm
Crossslide travsers: 860mm
Toolpost travsers: 400mm
Tailstock quill diameter: F260mm
Tailstock quill taper: Metric 80#
Quill traverse: 300mm
Main motor: 30kw
Coolant motor: 0.15kw
Rapid traverse motor: 1.5kw
Tailstock motor: 3kw
Standard accessorids: φ1250mm 4-jaw chuck, Steady rest:φ200-φ500,φ300-φ800
Optional accessories:Roll Support,bigger 4 jaw chuck
