Punch force (KN): 300
Table size (mm): 1250x2500
Table loading (kgs): 150
Max punching thickness (mm): 6.35
Punching stroke length (mm): 32
Stroke per min (spm): 360
Max punching diameter (mm): 88.9
No of tool station: 8
Punching accuracy (mm): ±0.10
X,Y travel speed (m/min): 50
CNC control axis: X,Y,T,C
Air pressure (MPa): 0.5~0.6
Motor power (kW): 20
Overall size (mm): 5140x3200x2170
Weight (T): 15
