Max drilling capacity(mm): F100
Distance between spindle axis and column(mm): Max: 2800
Min: 560
Horizontal travers of main spindle(mm): 2590
Distance b/w spindle end to worksurface plate(mm): Max: 2500
Min: 700
ARM lifting distance(mm): 1300
ARM lifting speed(m/s): 0.017
ARM swivel angle(°): 360°
Main spindle Morse No.: MT6
Main spindle Strokes(mm): 500
Main spindle Speed scope(rpm): 0,200,160,125,100,80,63,50,40,31.5,25,20,16,12.5,10,8
Main spindle Speed steps(no.): 22
Main spindle Feeding scope(mm/r): 3.2/2/1.56/1.25/0.8/0.63/0.5/0.32/0.25/0.2/0.16/0.13/0.1/0.06
Main spindle Feeding steps: 16
Drilling depth per scale(mm): 170
Max feeding force of main spindle(N): 50000
Max torque of main spindle(N.m): 2500
Main motor power(kw): 15
Lifting motor power(kw): 3
Clamping motors to spindle * arm(kw): 0.75
Coolant pumpt motor power(kw): 0.09
Machine weight(kg): 19000
Overall size(mm): 4530/4250/3850x1630x4795
Column diameter(mm): F600
Working table size(mm): 1250 x 800 x 560
Working table T slot (WxT)(mm): up 28 x 26, down 50 x 51
Working table T slot (WxT)(mm): up 28 x 26, down 46 x 48
Base plate size(mm): 4280 x 1630 x 330
Base plate operation area(mm): 3640 x 1600
