Output:
Compliance voltage: 0 to 50 V (bipolar)
Compliance voltage error: 0.5 % + 50 mV
DC output resistance: 1012 Ω (1 nA/V gain)
Output capacitance: <12 pF (filter off); <500 pF (filter on)
Guard output: -50 V to +50 V; 5 kΩ internal resistance
Output power: 5 W (four quadrant sourcing/sinking)
THD: 0.01 % typ.
Output connector: 3-lug Triax for current output; Banana jacks for load voltage monitoring
Common mode voltage: 250 Vrms (DC to 60 Hz)
Common mode isolation: >1 GΩ, <1 nF
Input:
Input range: -2 V to +2 V
Input impedance: 100 kΩ
Input connector: BNC
Remote Interfaces:
RS-232: DB-9 connector, 9600 baud
Optical fiber: Connection to SX199 Optical Interface Controller. Provides connectivity to GPIB, RS-232 and Ethernet
General:
Operating temperature: 0 °C to 40 °C, non-condensing
Power: <30 W, 100/120/220/240 VAC, 50 Hz or 60 Hz
Dimensions: 8.3" × 3.5" × 13.0" (WHL)
Weight: 10 lbs.
