Shutdown: Shutdown
Input Type: Differential/Single-Ended
Resolution: 12 bit
Output Type: CMOS
Architecture: SAR
Sampling Rate: 1 MS/s
Mounting Style: SMD/SMT
Number of Channels: 8 Channel
Number of Converters: 1 Converter
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 2.7 V
Analog Supply Voltage: 2.7 V to 3.6 V
FPBW - Full Power Bandwidth: 6.8 MHz
INL - Integral Nonlinearity: 0.3 LSB, 0.6 LSB
SNR - Signal to Noise Ratio: 71 dB, 73 dB
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
DNL - Differential Nonlinearity: 0.3 LSB, 0.5 LSB
ENOB - Effective Number of Bits: 11.4 bit, 11.6 bit
THD - Total Harmonic Distortion: - 80 dB
SFDR - Spurious Free Dynamic Range: 81 dB
SINAD - Signal to Noise and Distortion Ratio: 72 dB
