Fall Time: 20 ns
Rise Time: 14 ns
Technology: Si
Unit Weight: 76 mg
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 16.5 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 42 W
Vgs - Gate-Source Voltage: - 30 V, + 30 V
Typical Turn-On Delay Time: 12 ns
Typical Turn-Off Delay Time: 32 ns
Id - Continuous Drain Current: 4.5 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 800 mOhms
Vds - Drain-Source Breakdown Voltage: 800 V
Vgs th - Gate-Source Threshold Voltage: 3 V
