Shutdown: No Shutdown
Input Type: Rail-to-Rail
Technology: Si
Output Type: Rail-to-Rail
Unit Weight: 16.380 mg
Amplifier Type: Low Power Amplifier
Mounting Style: SMD/SMT
SR - Slew Rate: 1 V/us
THD plus Noise: 0.0005 %
Number of Channels: 1 Channel
Supply Voltage - Max: 36 V
Supply Voltage - Min: 4 V
Ib - Input Bias Current: 35 nA
Operating Supply Current: 380 uA
Vcm - Common Mode Voltage: 4 V to 36 V
Output Current per Channel: 65 mA
Vos - Input Offset Voltage: 1.5 mV
GBP - Gain Bandwidth Product: 2.5 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
en - Input Voltage Noise Density: 20 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 129 dB
