Shutdown: Shutdown
Output Type: Rail-to-Rail
Unit Weight: 21 mg
Qualification: AEC-Q100
Mounting Style: SMD/SMT
SR - Slew Rate: 2 V/us
THD plus Noise: 0.003 %
Number of Channels: 2 Channel
Supply Voltage - Max: 36 V
Supply Voltage - Min: 4 V
Ib - Input Bias Current: 5 nA
Operating Supply Current: 2.5 mA
Vcm - Common Mode Voltage: 37.5 V
Ios - Input Offset Current: 5 nA
Output Current per Channel: 200 mA
Vos - Input Offset Voltage: 2.4 mV
GBP - Gain Bandwidth Product: 3.1 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
en - Input Voltage Noise Density: 45 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 110 dB
PSRR - Power Supply Rejection Ratio: 130 dB
