Shutdown: No Shutdown
Input Type: Rail-to-Rail
Output Type: Rail-to-Rail
Unit Weight: 506.600 mg
Qualification: AEC-Q100
Amplifier Type: Operational Amplifier
Mounting Style: SMD/SMT
SR - Slew Rate: 340 mV/us
Number of Channels: 4 Channel
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 1.5 V
Ib - Input Bias Current: 10 pA
Operating Supply Current: 60 uA
Operating Supply Voltage: 5.5 V
Ios - Input Offset Current: 100 pA
Output Current per Channel: 74 mA
Vos - Input Offset Voltage: 3 mV
GBP - Gain Bandwidth Product: 880 kHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
en - Input Voltage Noise Density: 60 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 60 dB
