Frequency Range: 9kHz~7.5GHz
Resolution: 1Hz
Aging Rate: ≤1*10^-6/year
Frequency Span
Frequency Span Range: 0Hz, 100Hz~7.5GHz
Uncertainty: ±span/(sweep points-1)
SSB Phase Noise(fc=1.0GHz): -96dBc/Hz @ 10 kHz offset
Bandwidth
Resolution Bandwidth (-3dB): 10Hz~1MHz, step 1-3-10
RBW Uncertainty
10%, nominal (RBW>1kHz)
20%, nominal(RBW≥10Hz, sweep time≥5s)
Video Bandwidth (-3dB): 1Hz to 1MHz, step 1-3-10
Amplitude
Range: DANL to +20dBm
Maximum Input Level
DC Voltage: 50V
CW RF Power: +20dBm (0.1W)
Max.Damage Level: +30dBm (1W)
Input/Output
RF Input Impedance: 50 Ω
Standard frequency
Frequency: 10MHz
Amplitude: 0dBm~10dBm (input) -3dBm to +3dBm (output)
Interface
Type: USB Host & Device, LAN, VGA
General Characteristic
Power Supply
Input Voltage: AC100V to 240V
Frequency: 50/60Hz (1±10%)
Power Consumption: 35W
Dimension & Weight: 363*154*327 mm, Approx. 6.5kg
Standard Accessories
Power Cord: 1pcs
N-BNC Adapter: 1pcs
CD(Software+ User's Guide): 1pcs
