Frequency Range: 5Hz ~ 3MHz
Measurement Range
AC Voltage: 50µV ~ 400V
Scale: 3mV, 30mV, 300mV, 3V, 30V, 300V
dBV: -86dBV ~ 52dBV
dBm
-73dbm ~ 65.05dbm (R=50Ω)
-84dbm ~ 54.26dbm (R=600Ω)
Vpp: 141µV ~ 1131.3Vpp
dB: -86dB~52.04dB
Voltage Measurement Error
≥5Hz ~ 100Hz: ±2.5% reading ± 0.8% range
>100Hz ~ 500kHz: ±1.5% reading ± 0.5% range
>500kHz ~ 2MHz: ±2.0% reading ± 1.0% range
>2MHz ~ 3MHz: ±3.0% reading ± 1.0% range
>3MHz ~ 5MHz: ±4.0% reading ± 2.0% range
>5MHz ~ 6MHz: ±5.0% reading ± 4.0% range
Resolution
Range (3 1/2 digits Display)
3mV/ 0.001mV
30mV/ 0.01mV
300mV/ 0.1mV
3V/ 0.001V
30V/ 0.01V
300V/ 0.1V
Maximum Undamaged Input Voltage
Range:300V400Vrms
General Characteristics
Power: AC220(1±10%)V, 50 (1±5%)Hz, < 20VA
Interface: USB Device
Display: LED display
Dimension & Weight: 260×106×375 mm, Approx.3.9 kg
Standard Accessories
Power Cord: 1pcs
Test clip leads: 2pcs
CD(Software+ User's Guide): 1pcs
Application
Factory, Lab, R&D institution, Troops, Colleges and Universities
Design Features
1. LED display, dual independent channels
2. Auto/Manual ranging can be selected.
3. Multi display result with different units.
4. Standard interface USB device and optional LAN interface
