Machine dimension(mm): 1572L*1070W*1250H
PCB Size(mm): Min：70L*70W*0.7H~Max：530L*460W*3H
Carrier size(Pallet size) (mm): 535L*530W*570H; Weight Approx 12.3kg
Approx machine weight: 300kg
Power: 0.5KW
Total allowed loading number of the carrier: 3
Conveying height: 900±20mm
Stepping choice: 10mm，20mm，30mm，40mm，50mm
Control mode: PLC
Production cycle: ≤10/s
Powersupply: AC220V 50/60Hz
Gas pressure: 0.4~0.7MPa
Direction: L to R(Options：R to L)
