Standards: ISO 8041-1:2017
Vibration Accelerations (RMS in m/s²)
1 (at 15.92 Hz)
1; 2; 3; 4; 5; 6; 7; 8; 9; 10 (at 79.58 Hz)
1; 2; 3; 4; 5; 6; 7; 8; 9; 10 (at 159.2 Hz)
1 (at 636.6 Hz)
Vibration Velocities (RMS in mm/s)
10 (at 15.92 Hz)
2; 4; 6; 8; 10; 12; 14; 16; 18; 20 (at 79.58 Hz)
1; 2; 3; 4; 5; 6; 7; 8; 9; 10 (at 159.2 Hz)
0.25 (at 636.6 Hz)
Vibration Displacement (RMS in µm)
100 (at 15.92 Hz)
4; 8; 12; 16; 20; 24; 28; 32; 36; 40 (at 79.58 Hz)
1; 2; 3; 4; 5; 6; 7; 8; 9; 10 (at 159.2 Hz)
0.0625 (at 636.6 Hz)
Accuracy
Amplitude Error: Less than ±3 %
Frequency Error: Less than ±0.5 %
Transverse Vibration: Less than 10 % of the main direction
Harmonic Distortion
<5% (at 15.92 Hz)
<3% (at 79.58 Hz)
<3% (at 159.2 Hz)
<3% (at 636.6 Hz)
Maximum Weight of Calibrated Object:
1000 grams (at 15.92 Hz)
300 grams (at 79.58 Hz)
200 grams (at 159.2 Hz)
200 grams (at 636.6 Hz)
Power Supply:
Rechargeable battery 6 V / 12 Ah
Operation time up to 20 hours
Charging Time: Less than 10 hours
Power Supply for Charger: SA 33 (12 V / 1 A) or 15 W, 8 ÷ 24 V
Environmental Conditions
Temperature: from -10 °C to 50 °C (14 °F to 122 °F)
Humidity: 25 % ÷ 85 % RH, non-condensed
Dimensions: 395 × 270 × 194 mm
Weight: 8.2 kg (incl. battery)
