Temperature Range: 5℃ above RT to 70℃
Shaking motion: Reciprocal/Orbital
Temp. control accuracy (*1): ±0.2 to ±0.4℃
Speed range: 20 to 300 r/min (200 r/min at the upper of stacked units),
Shaking width: 25mm（≒1inch）
Platform size: 290 × 250 mm (Max. inside height: FP/FH = 270 mm, UM = 315 mm)
Capacity: Erlenmeyer flask 500 mL × 4, 2 L × 1
Door Style: Single swing door (Leftward open)
Maximum load: Approx. 3.5 kg (Platform and Vessel holder included)
Ambient temp. range: +5℃ to +35℃
Heating method: Heater (350 W)
Display (Temp. and speed): Digital display
Program functions: 1 program, 9 segments: Temp., Shaking speed and time/per segment (Setting range: 00 h 00 min to 99 h 59 min), Temp. gradient function (*2)
Safety devices/functions: Leakage/Overcurrent breaker, Fuse, Alarm of abnormal sample temp. (Set as desired), Detecting the door opening and closing, Self-diagnosis function for sensor error, Motor current limiter, Overcurrent protection of Peltier (FP)
Dimensions: 422 × 550 × 540H mm
Weight: Approx. 43 kg
Power supply (*3): AC100V/5A (Need a step-down transformer)
Standard accessories: Drain nozzle ×1pc, Drain hose ×1pc
(*1)The value at the ambient temperature is 25℃. Also, the specifications may not be met outside of the ambient temperature range.
(*2)The transfer time of temperature can be set up.
(*3)Voltage variation rate is ±5% for AC 100 V.
